Description
8 Megapixel IP Plug & Play, Outdoor Turret, Fixed Lens, IR Range up to 98’, WDR, Audio Input, Built-in Mic, SD Card Slot, DC12V/PoE
Features
- True AI Human and Vehicle Classification for Line Crossing and Intrusion Detection
- 8 Megapixel Resolution
- Fixed Lens
- True Day/Night with IR Range up to 98’
- H.265+,H.265,H.264+,H.264,MJPEG Compression
- 30 FPS Recording and Live
- WDR
- Smart Analytics
- Micro SD Slot: Up to 256GB
- Audio Input: Built-in Mic
- IP67 Weatherproof
- 12VDC/PoE Operation
- ONVIF
- Free iOS & Android Apps for Smart Phones & Tablets
- Free Central Management Software (CMS)
- Free MAC Client
Camera |
|
|
Image Sensor |
1 / 2.8” CMOS |
|
Image Size |
3840 x 2160 |
|
Electronic Shutter |
1 s ~ 1 / 100000 s |
|
Iris Type |
Fixed Iris |
|
Min. Illumination |
0.01 lux @ F1.2, AGC ON; 0 lux with IR |
|
0.02 lux@F1.6, AGC ON; 0 lux with IR |
|
|
Lens |
2.8mm@F1.6, Horizontal FoV:109.7°;Vertical FoV:77.2°;Diagonal FoV:116.9° |
|
Focus |
Fixed |
|
Lens Mount |
M12 |
|
Day & Night |
ICR |
|
Wide Dynamic Range |
120dB |
|
BLC |
Yes |
|
HLC |
Yes |
|
Defog |
Yes |
|
Digital NR |
3D DNR |
|
Angle Adjustment |
Pan: 0° ~ 360°; Tilt:0° ~ 75°; Rotation: 0° ~ 360° |
Image |
|
|
Video Compression |
Main Stream: H.265+ / H.265 / H.264+ / H.264 Sub Stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG Third Stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
|
H.264 Compression Standard |
Baseline Profile/Main Profile/High Profile |
|
Resolution |
8MP ( 3840 x 2160 ), 6MP( 3072 x 2048 ),5MP( 2592 x 1944), 4MP( 2592 x 1520 ), 2K ( 2560 x 1440 ), 3MP ( 2304 x 1296 ), 1080P ( 1920 x 1080 ), 720P ( 1280 x 720 ), D1, CIF, 480 x 240 |
|
Main Stream |
60Hz : 8MP/6MP/5MP/4MP/2K/3MP/1080P/720P(1~30fps) 50Hz : 8MP/6MP/5MP/4MP/2K/3MP/1080P/720P(1~25fps) HFR Mode: 1080P/720P(60Hz: 1~60fps; 50Hz: 1~50fps) |
|
Sub Stream |
720P/D1/CIF/480 x 240 (60Hz: 1~30fps; 50Hz: 1~25fps) |
|
Third Stream |
D1/CIF/480 40 (60Hz: 1~30fps; 50Hz: 1~25fps) |
|
Bit Rate |
64 Kbps ~ 12 Mbps |
|
Bit Rate Type |
VBR / CBR |
|
Audio Compression |
G711A / U |
|
Image Settings |
ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, NR,etc. adjustable through client software or web browser |
|
ROI |
Each ROI to be configured separately |
Intelligent Analytics (Smart Events) |
|
|
Perimeter Protection |
Line crossing, intrusion |
|
Target Counting |
Line crossing human/motor vehicle/non-motor vehicle counting |
|
Exception Detection |
Scene change, video blur and video color cast detection |
|
Face Detection |
Face detection and face capture |
Interfaces |
|
|
Network |
RJ45 |
|
Video Output |
No |
|
Audio |
1CH audio input ; 1CH built-in MIC |
|
Storage |
Built-in micro SD card slot; up to 256GB |
|
Reset |
Yes |
Functions |
|
|
Remote Monitoring |
Web browsing,CMS remote control |
|
Online Connection |
Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission |
|
Network Protocol |
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP,HTTP, 802.1x, UPnP, HTTPs, QoS |
|
Interface Protocol |
ONVIF |
|
Storage |
Network remote storage; micro SD card storage |
|
Smart Alarm |
Motion detection; SD card error; SD card full |
|
General Function |
Watermark, IP address filtering, video mask, heartbeat, illegal login lock, etc. |
|
PoE |
Yes , IEEE802.3af |
|
IR Distance |
98 ft (20~30 m) |
|
Ingress Protection |
IP67 |
Others |
|
|
Power Supply |
DC12V/PoE |
|
Power Consumption |
< 9W |
|
Operating Environment |
-22°F ~ 140°F (- 30 °C ~ 60 °C) Humidity: less than 95 % (non-condensing) |
|
Dimensions |
3.7 x 3.3 in (94.6 x 82.8 mm) |
|
Weight ( net ) |
Approx. 1lb (.46KG) |
|
Installation |
Ceiling mounting; Wall mounting |
|
Certificate |
CE, FCC, ETL: 5025761 |
|
Environmental |
Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006) |
